Bravair Home JYBG
Wall-mounted Fan Coil with a modern, minimalist design.
The wall-mounted models of the JYBG Fan Coil series ensure high efficiency thanks to their gold-plated copper heat exchanger, which also has an internal spiral shape for maximum heat transfer.
Power consumption and noise levels are kept to a minimum thanks to the adjustable BLDC fan motor that minimizes friction.
They also include a water temperature sensor, which provides higher levels of comfort by ensuring that the fan only runs when the water temperature is right.
The biodegradable and recyclable high-impact polystyrene shell makes the product environmentally friendly while at the same time giving it UV resistance to maintain its color.
The wall-mounted models of the JYBG Fan Coil series ensure high efficiency thanks to their gold-plated copper heat exchanger, which also has an internal spiral shape for maximum heat transfer.
Power consumption and noise levels are kept to a minimum thanks to the adjustable BLDC fan motor that minimizes friction.
They also include a water temperature sensor, which provides higher levels of comfort by ensuring that the fan only runs when the water temperature is right.
The biodegradable and recyclable high-impact polystyrene shell makes the product environmentally friendly while at the same time giving it UV resistance to maintain its color.
Specifications
| Model | Bravair Home JYBG-2P | Bravair Home JYBG-3P |
|---|---|---|
| Cooling capacity (Outlet 7°C) | 4kW | 5.5kW |
| Heating capacity (Outlet 50°C) | 5.3kW | 6.4kW |
| Heating capacity (Outlet 70°C) | 7.2kW | 8.5kW |
| Air flow rate | 620m3/h | 1100 m3/h |
| Nominal water flow rate | 0.75 m3/h | 0.94 m3/h |
| Noise level | 18-36dB | 20-40dB |
| Maximum power consumption | 18W | 45W |
| Dimensions | 850x265x210mm | 1100x330x250mm |
| Weight | 10kg | 15kg |
| Water connections (in) | ½’’ | ¾’’ |
